Privacy for Tigers

As mobile phone masts went up across the world’s jungles, savannas and mountains, so did poaching. Wildlife crime syndicates can not only coordinate better but can mine growing public data sets, often of geotagged images. Privacy matters for tigers, for snow leopards, for elephants and rhinos – and even for tortoises and sharks. Animal data protection laws, where they exist at all, are oblivious to these new threats, and no-one seems to have started to think seriously about information security.

So we have been doing some work on this, and presented some initial ideas via an invited talk at Usenix Security in August. A video of the talk is now online.

The most serious poaching threats involve insiders: game guards who go over to the dark side, corrupt officials, and (now) the compromise of data and tools assembled for scientific and conservation purposes. Aggregation of data makes things worse; I might not care too much about a single geotagged photo, but a corpus of thousands of such photos tells a poacher where to set his traps. Cool new AI tools for recognising individual animals can make his work even easier. So people developing systems to help in the conservation mission need to start paying attention to computer security. Compartmentation is necessary, but there are hundreds of conservancies and game reserves, many of which are mutually mistrustful; there is no central authority at Fort Meade to manage classifications and clearances. Data sharing is haphazard and poorly understood, and the limits of open data are only now starting to be recognised. What sort of policies do we need to support, and what sort of tools do we need to create?

This is joint work with Tanya Berger-Wolf of Wildbook, one of the wildlife data aggregation sites, which is currently redeveloping its core systems to incorporate and test the ideas we describe. We are also working to spread the word to both conservators and online service firms.

Making sense of the Supermicro motherboard attack

There has been a lot of ‘fog of war’ regarding the alleged implantation of Trojan hardware into Supermicro servers at manufacturing time. Other analyses have cast doubt on the story. But do all the pieces pass the sniff test?

In brief, the allegation is that an implant was added at manufacturing time, attached to the Baseboard Management Controller (BMC). When a desktop computer has a problem, common approaches are to reboot it or to reinstall the operating system. However in a datacenter it isn’t possible to physically walk up to the machine to do these things, so the BMC allows administrators to do them over the network.

Crucially, because the BMC has the ability to install the operating system, it can disrupt the process that boots the operating system – and fetch potentially malicious implant code, maybe even over the Internet.

The Bloomberg Businessweek reports are low on technical details, but they do show two interesting things. The first is a picture of the alleged implant. This shows a 6-pin silicon chip inside a roughly 1mm x 2mm ceramic package – as often used for capacitors and other so-called ‘passive’ components, which are typically overlooked.

The other is an animation highlighting this implant chip on a motherboard. Extracting the images from this animation shows the base image is of a Supermicro B1DRi board. As others have noted, this is mounted in a spare footprint between the BMC chip and a Serial-Peripheral Interface (SPI) flash chip that likely contains the BMC’s firmware. Perhaps the animation is an artist’s concept only, but this is just the right place to compromise the BMC.

SPI is a popular format for firmware flash memories – it’s a relatively simple, relatively slow interface, using only four signal wires. Quad SPI (QSPI), a faster version, uses six wires for faster transmission. The Supermicro board here appears to have a QSPI chip, but also a space for an SPI chip as a manufacturing-time option. The alleged implant is mounted in part of the space where the SPI chip would go. Limited interception or modification of SPI communication is something that a medium complexity digital chip (a basic custom chip, or an off-the-shelf programmable CPLD) could do – but not to a great extent. Six pins is enough to intercept the four SPI wires, plus two power. The packaging of this implant would, however, be completely custom.

What can an implant attached to the SPI wires do? The BMC itself is a computer, running an operating system which is stored in the SPI flash chip. The manual for a MBI-6128R-T2 server containing the B1DRi shows it has an AST2400 BMC chip.

The AST2400 uses a relatively old technology – a single-core 400MHz ARM9 CPU, broadly equivalent to a cellphone from the mid 2000s. Its firmware can come via SPI.

I downloaded the B1DRi BMC firmware from the Supermicro website and did some preliminary disassembly. The AST2400 in this firmware appears to run Linux, which is plausible given it supports complicated peripherals such as PCI Express graphics and USB. (It is not news to many of us working in this field that every system already has a Linux operating system running on an ARM CPU, before power is even applied to the main Intel CPUs — but many others may find this surprising).

It is possible that the implant simply replaces the entire BMC firmware, but there is another way.

In order to start its own Linux, AST2400 boots using the U-Boot bootloader. I noticed one of the options is for the AST2400 to pick up its Linux OS over the network (via TFTP or NFS). If (and it’s a substantial if) this is enabled in the AST2400 bootloader, it would not take a huge amount of modification to the SPI contents to divert the boot path so that the BMC fetched its firmware over the network (and potentially the Internet, subject to outbound firewalls).

Once the BMC operating system is compromised, it can then tamper with the main operating system. An obvious path would be to insert malicious code at boot time, via PCI Option ROMs. However, after such vulnerabilities came to light, defenses have been increased in this area.

But there’s another trick a bad BMC can do — it can simply read and write main memory once the machine is booted. The BMC is well-placed to do this, sitting on the PCI Express interconnect since it implements a basic graphics card. This means it potentially has access to large parts of system memory, and so all the data that might be stored on the server. Since the BMC also has access to the network, it’s feasible to exfiltrate that data over the Internet.

So this raises a critical question: how well is the BMC firmware defended? The BMC firmware download contains raw ARM code, and is exactly 32MiB in size. 32MiB is a common size of an SPI flash chip, and suggests this firmware image is written directly to the SPI flash at manufacture without further processing. Additionally, there’s the OpenBMC open source project which supports the AST2400. From what I can find, installing OpenBMC on the AST2400 does not require any code signing or validation process, and so modifying the firmware (for good or ill) looks quite feasible.

Where does this leave us? There are few facts, and much supposition. However, the following scenario does seem to make sense. Let’s assume an implant was added to the motherboard at manufacture time. This needed modification of both the board design, and the robotic component installation process. It intercepts the SPI lines between the flash and the BMC controller. Unless the implant was designed with a very high technology, it may be enough to simply divert the boot process to fetch firmware over the network (either the Internet or a compromised server in the organisation), and all the complex attacks build from there — possibly using PCI Express and/or the BMC for exfiltration.

If the implant is less sophisticated than others have assumed, it may be feasible to block it by firewalling traffic from the BMC — but I can’t see many current owners of such a board wanting to take that risk.

So, finally, what do we learn? In essence, this story seems to pass the sniff test. But it is likely news to many people that their systems are a lot more complex than they thought, and in that complexity can lurk surprising vulnerabilities.

Dr A. Theodore Markettos is a Senior Research Associate in hardware and platform security at the University of Cambridge, Department of Computer Science and Technology.

How Protocols Evolve

Over the last thirty years or so, we’ve seen security protocols evolving in different ways, at different speeds, and at different levels in the stack. Today’s TLS is much more complex than the early SSL of the mid-1990s; the EMV card-payment protocols we now use at ATMs are much more complex than the ISO 8583 protocols used in the eighties when ATM networking was being developed; and there are similar stories for GSM/3g/4g, SSH and much else.

How do we make sense of all this?

Reconciling Multiple Objectives – Politics or Markets? was particularly inspired by Jan Groenewegen’s model of innovation according to which the rate of change depends on the granularity of change. Can a new protocol be adopted by individuals, or does it need companies to adopt it en masse for internal use, or does it need to spread through a whole ecosystem, or – the hardest case of all – does it require a change in culture, norms or values?

Security engineers tend to neglect such “soft” aspects of engineering, and we probably shouldn’t. So we sketch a model of the innovation stack for security and draw a few lessons.

Perhaps the most overlooked need in security engineering, particularly in the early stages of a system’s evolution, is recourse. Just as early ATM and point-of-sale system operators often turned away fraud victims claiming “Our systems are secure so it must have been your fault”, so nowadays people who suffer abuse on social media can find that there’s nowhere to turn. A prudent engineer should anticipate disputes, and give some thought in advance to how they should be resolved.

Reconciling Multiple Objectives appeared at Security Protocols 2017. I forgot to put the accepted version online and in the repository after the proceedings were published in late 2017. Sorry about that. Fortunately the REF rule that papers must be made open access within three months doesn’t apply to conference proceedings that are a book series; it may be of value to others to know this!

BBC Horizon documentary: A Week without lying, the honesty experiment

Together with Ronald Poppe, Paul Taylor, and Gordon Wright, Sophie van der Zee (previously employed at the Cambridge Computer Laboratory), took a plunge and tested their automated lie detection methods in the real world. How well do the lie detection methods that we develop and test under very controlled circumstances in the lab, perform in the real world? And what happens to you and your social environment when you constantly feel monitored and attempt to live a truthful life? Is living a truthful life actually something we should desire? Continue reading BBC Horizon documentary: A Week without lying, the honesty experiment

Google doesn’t seem to believe booters are illegal

Google has a number of restrictions on what can be advertised on their advert serving platforms. They don’t allow adverts for services that “cause damage, harm, or injury” and they don’t allow adverts for services that “are designed to enable dishonest behavior“.

Google don’t seem to have an explicit policy that says you cannot advertise a criminal enterprise : perhaps they think that is too obvious to state.

Nevertheless, the policies they written down might lead you to believe that advertising “booter” (or as they sometimes style themselves to appear more legitimate) “stresser” services would not be allowed. These are websites that allow anyone with a spare $5.00 or so to purchase distributed denial of service (DDoS) attacks.

Booters are mainly used by online game players to cheat — by knocking some of their opponents offline — or by pupils who down the school website to postpone an online test or just because they feel like it. You can purchase attacks for any reason (and attack any Internet system) that you want.

These booter sites are quite clearly illegal — there have been recent arrests in Israel and the Netherlands and in the UK Adam Mudd got two years (reduced to 21 months on appeal) for running a booter service. In the USA a New Mexico man recently got a fifteen year sentence for merely purchasing attacks from these sites (and for firearms charges as well).

However, Google doesn’t seem to mind booter websites advertising their wares on their platform. This advert was served up a couple of weeks back:

advert for booter

I complained using Google’s web form — after all, they serve up lots of adverts and their robots may not spot all the wickedness. That’s why they have reporting channels to allow them to correct mistakes. Nothing happened until I reached out to a Google employee (who spends a chunk of his time defending Google from DDoS attacks) and then finally the advert disappeared.

Last week another booter advert appeared:

but another complaint also made no difference and this time my contact failed to have any impact either, and so at the time of writing the advert is still there.

It seems to me that, for Google, income is currently more important than enforcing policies.

Bitter Harvest: Systematically Fingerprinting Low- and Medium-interaction Honeypots at Internet Scale

Next week we will present a new paper at USENIX WOOT 2018, in which we show that we can find low- and medium-interaction honeypots on the Internet with a few packets. So if you are running such a honeypot (Cowrie, Glastopf, Conpot etc.), then “we know where you live” and the bad guys might soon as well.

In total, we identify 7,605 honeypot instances across nine different honeypot implementations for the most important network protocols SSH, Telnet, and HTTP.

These honeypots rely on standard libraries to implement large parts of the transport layer, but they were never intended to provide identical behaviour to the systems being impersonated. We show that fixing the identity string pretending to be OpenSSH or Apache and not “any” library or fixing other common identifiers such as error messages is not enough. The problem is that there are literally thousands of distinguishing protocol interactions, part of the contribution of the paper is to show how to pick the “best” one. Even worse, to fingerprint these honeypots, we do not need to send any credentials so it will be hard to tell from the logging that you have been detected.

We also find that many honeypots are deployed and forgotten about because part of the fingerprinting has been to determine how many people are not actively patching their systems! We find that  27% of the SSH honeypots have not been updated within the last 31 months and only 39% incorporate improvements from 7 months ago. It turns out that security professionals are as bad as anyone.

We argue that our method is a  ‘class break’ in that trivial patches cannot address the issue. Thus we need to move on from the current dominant honeypot architecture of python libraries and python programs for low- and medium-interaction honeypots. We also have developed a modified version of the OpenSSH daemon (sshd) which can front-end a Cowrie instance so that the protocol layer distinguishers will no longer work.

The paper is available here.

The two-time pad: midwife of information theory?

The NSA has declassified a fascinating account by John Tiltman, one of Britain’s top cryptanalysts during world war 2, of the work he did against Russian ciphers in the 1920s and 30s.

In it, he reveals (first para, page 8) that from the the time the Russians first introduced one-time pads in 1928, they actually allowed these pads to be used twice.

This was still a vast improvement on the weak ciphers and code books the Russians had used previously. Tiltman notes ruefully that “We were hardly able to read anything at all except in the case of one or two very stereotyped proforma messages”.

Now after Gilbert Vernam developed encryption using xor with a key tape, Joseph Mauborgne suggested using it one time only for security, and this may have seemed natural in the context of a cable company. When the Russians developed their manual system (which may have been inspired by the U.S. work or a German one-time pad developed earlier in the 1920s) they presumably reckoned that using them twice was safe enough.

They were spectacularly wrong. The USA started Operation Venona in 1943 to decrypt messages where one-time pads had been reused, and this later became one of the first applications of computers to cryptanalysis, leading to the exposure of spies such as Blunt and Cairncross. The late Bob Morris, chief scientist at the NSA, used to warn us enigmatically of “The Two-time pad”. The story up till now was that the Russians must have reused pads under pressure of war, when it became difficult to get couriers through to embassies. Now it seems to have been Russian policy all along.

Many people have wondered what classified war work might have inspired Claude Shannon to write his stunning papers at the end of WW2 in which he established the mathematical basis of cryptography, and of information more generally.

Good research usually comes from real problems. And here was a real problem, which demanded careful clarification of two questions. Exactly why was the one-time pad good and the two-time pad bad? And how can you measure the actual amount of information in an English (or Russian) plaintext telegram: is it more or less than half the amount of information you might squeeze into that many bits? These questions are very much sharper for the two-time pad than for rotor machines or the older field ciphers.

That at least was what suddenly struck me on reading Tiltman. Of course this is supposition; but perhaps there are interesting documents about Shannon’s war work to be flushed out with freedom of information requests. (Hat tip: thanks to Dave Banisar for pointing us at the Tiltman paper.)

Graphical Models of Security (GraMSec 2018)

I was at The Fifth International Workshop on Graphical Models for Security (part of FLoC 2018) this weekend where I presented a paper. Following is a summarized account of the talks that took place there. Slides can be found here.

The first speaker was Mike Fisk who was giving an invited talk on Intrusion Tolerance in Complex Cyber Systems. Mike started off by elaborating the differences in the construction of physically secure systems such as forts versus the way software engineers go about creating so-called secure systems. He then made the case for thinking in terms of intrusion tolerance rather than just intrusion resistance – even if an intruder gets in, your system should be designed in such a way that it impedes the intruder’s exploration of your network. He then instantiated this idea by talking about credentials for accessing network resource and how they’re stored. He noted that normal users (with the notable exceptions of sysadmins) show predictable access patterns whereas attackers show wildly different access patterns; an intrusion tolerant system should take these into account and ask for re-authentication in case of abnormal patterns. He then talked about metrics for figuring out which nodes in a network are most interesting to an attacker. While some of these are expected – say, the ActiveDirectory server – others are quite surprising such as regular desktops with very high network centrality. He concluded by giving advise on how to use these metrics to direct resources for intrusion resistance most effectively.

Sabarathinam Chockalingam gave a talk on using Bayesian networks and fishbone diagrams to distinguish between intentional attacks and accidental technical failures in cyber-physical systems. His work focused specifically on water level sensors used in floodgates. He first gave an introduction to fishbone diagrams highlighting their salient features such as the ability to facilitate brainstorming sessions while showcasing all the relevant factors in a problem. He then presented a way to translate fishbone diagrams into Bayesian networks. He utilized this technique to convert the risk factor fishbone diagram for the water level sensors into a Bayesian network and generated some predictions. These predictions were mostly based on expert knowledge and literature review. He concluded by pointing at some possible future research directions primary of which was exploring the conversion of fishbone diagrams into conditional probability tables.

I gave a talk on visualizing the diffusion of stolen bitcoins. This works builds upon our previous work on applying the FIFO algorithm to tainting bitcoins, presented at SPW2018. Here, I focused on the challenges facing effective visualization of the tainting dataset. I highlighted the size of the dataset (>450 GB for just 56 kinds of taint), the unbounded number of inputs and outputs as well as the unbounded number of hops a satoshi can take. All these make visualization without abstraction challenging. We refused to use lossy abstractions since what is interesting to the user might be something that we abstract away. Instead, we made two prototypes that, for the most part, convey the underlying information in an accessible manner to the end-user without using any abstractions. The first provides a static map of the taint-graph, useful for getting a global view of the graph; the second provides an interactive way to explore individual transactions. I concluded by pointing out that this is a much more general problem since what we are trying to do is visualize a large subset of transactions in a massive dataset – something that is encountered in many other domains.

Ross Horne presented a specialization of attack trees where he took into consideration of an attacker about the underlying system that they are trying to compromise. He pointed out that existing attack trees assume perfect knowledge on the part of the attacker whereas this is not realistic. The attacker often acts under uncertainty. To model this, he introduced a new operator to act between branches of an attack tree that conveys ignorance on the effectiveness and possible outcomes in case the attacker chooses to traverse that sub-tree. He then introduced a way of reasoning about the specialization of such trees and showed how the placement of the newly introduced operator has varying impact on the capabilities of the attacker. He concluded by remarking how these new attack trees could be used for moving target defence.

Harley Eades III gave a talk on applying linear logic to attack trees. He started off by pointing out that when understanding the difficulty of execution of an attack, we only care about the weights assigned to the leaves of the tree, the root nodes only serve as combinatorial operators. He then presented an exhaustive list of operators and provided a representation to convert attack trees into linear logic statements. He then introduced Maude, a quarternary semantics of attack trees followed by the introduction of Lina, an embedded domain specific programming language. Lina is used to do automated reasoning about attack trees using Maude. He presented Lina’s functionalities and showed an example application of Lina: automated threat analysis. He concluded by talking about future work conjecturing different formal models of causal attack trees specifically mentioning a petri net model.

Responsible vulnerability disclosure in Europe

There is a report out today from the European economics think-tank CEPS on how responsible vulnerability disclosure might be harmonised across Europe. I was one of the advisers to this effort which involved not just academics and NGOs but also industry.

It was inspired in part by earlier work reported here on standardisation and certification in the Internet of Things. What happens to car safety standards once cars get patched once a month, like phones and laptops? The answer is not just that safety becomes a moving target, rather than a matter of pre-market testing; we also need a regime whereby accidents, hazards, vulnerabilities and security breaches get reported. That will mean responsible disclosure not just to OEMs and component vendors, but also to safety regulators, standards bodies, traffic police, insurers and accident victims. If we get it right, we could have a learning system that becomes steadily safer and more secure. But we could also get it badly wrong.

Getting it might will involve significant organisational and legal changes, which we discussed in our earlier report and which we carry forward here. We didn’t get everything we wanted; for example, large software vendors wouldn’t support our recommendation to extend the EU Product Liability Directive to services. Nonetheless, we made some progress, so today’s report can be seen a second step on the road.
